Raritan - DKX3-108
8-port KVM-over-IP switch (1 remote user, 1 local user, VGA, DVI, HDMI, DisplayPort, serial)
Producentens varenummer:
DKX3-108
Vores artikelnummer:
211425
Har du spørgsmål? Vi vil med glæde rådgive dig! → Kontaktformular
Produktinformation "Raritan - DKX3-108"
The Dominion KX III is Raritan's flagship enterprise KVM-over-IP switch. It enables BIOS-level remote management of 8, 16, 32 or 64 servers by 1, 2, 4 or 8 users in a single switch. With industry-leading video performance, security as well as high reliability, the Dominion KX III clearly stands out from other models. With standard features such as DVI/HDMI/DisplayPort digital video, VGA analogue video, audio, virtual media, smart card/CAC and mobile access, the Dominion KXIII is suitable for any industry and application. With the new DSAM modules, you can manage up to 8 serial devices. The new KX III client SDK and API enable integration and automation.
The Dominion KX III is ideal for server rooms, test labs and large enterprise data centres. It provides powerful web-based remote management of servers, storage and network devices and virtually any application. It can be used standalone or with Raritan's CommandCenter Secure Gateway.
Scope of delivery: Raritan DKX3-108
The Dominion KX III is ideal for server rooms, test labs and large enterprise data centres. It provides powerful web-based remote management of servers, storage and network devices and virtually any application. It can be used standalone or with Raritan's CommandCenter Secure Gateway.
Scope of delivery: Raritan DKX3-108
| Classification: | Enterprise |
|---|---|
| Connection: | over IP |
| Graphic Port: | DVI |
| KVM Ports: | 8 Ports |
| Local Users: | 1 User |
| Power Supply: | Dual AC |
| Remote Users: | 1 User |
Features
- Better MTTR & availability
- Less travel
- Higher productivity
- Improved security
- Remote BIOS-level access and control
- Impressively powerful audio and video features
- Virtual Media
- Digital and analogue video
- Military-grade security features
- Java-free operation
- Two-factor authentication
- Mobile access
- Up to 8 true serial ports
- Redundancy for reliability
- Remote power control
- CC-SG integration
- KX III SDK and API
Technical details
Local access port
Examples of resolutions
- Form factor: 1U and 2U, full width, rack mountable (brackets included)
- Operating temperature: 0º - 45º C
- Humidity: 0% - 85% RH
- Remote connection Network: Dual 10/100/1000 Gigabit Ethernet access; Dual stack: IPv4 and IPv6
- Modem port protocols: DB9(F) DTETCP/IP, HTTP, HTTPS, UDP, RADIUS, SNTP, DHCP, PAP, CHAP, LDAP, SNMP v2 and v3
Local access port
- Video: Single Link DVI-D (F)
- Keyboard/mouse: USB (F), 1 USB on front, 3 USB on rear
- Tiering port: RJ45
Examples of resolutions
- PC text mode: 640x350, 640x480, 720x400
- PC graphics mode: 640x480, 800x600, 1024x768, 1152x864, 1280x1024, 1440x900, 1680x1050, 1600x1200, 1920x1080, 1920x1200
- Sun video mode: 1024x768, 1152x864, 1152x900, 1280x1024
