Nexmosphere - XY-231
Product information "Nexmosphere - XY-231"
XY Range
The Nexmosphere XY range offers a variety of sensors for detecting and analyzing the presence, distance, and demographics of the people in front of your interactive display or signage installation. Whether you want to increase the impact by triggering the right content at the right time, want to program attractive lighting changes and increase engagement or want to collect valuable data, the XY range has a sensor which provides the input to do so.
The X-Eye Presence & Airbutton sensor is an IR Time-of-Flight sensor which can detect if an object or person is present, and if so, indicate the distance to the person. This enables implementation of multiple trigger zones, such as head-turning lighting effects on connected LED lighting when a person is far away and the appearance of call-to-action video content when they approach. Next to this, the sensor has a dedicated Airbutton zone for detecting touchless input of the user, simply by placing a hand in front of the sensor.
X-talk
The X-Eye Presence & Airbutton sensor can easily be connected to any of the Nexmosphere Xperience controllers using the X-talk interface. All settings of the XY sensor are programmable on the controller, enabling a seamless integration in your application.
- Plug and smile interface
- Compatible with any Nexmosphere Xperience controller
- Powered by and programmable with Nexmosphere Xperience controller
Presence & Airbutton detection
Presence & Airbutton sensors can be highly valuable to trigger your experience to start at just the right moment. Trigger your presentation to come alive when the shopper approaches the display and activate interactive content as soon as the shopper provides touchless user input by placing their hand in front of the sensor.
- 10 distance zones available, 25cm each (total 0-250cm)
- Dedicated Airbutton zone for touchless user input
- Adjustable settings and Field-of-View
Benefits
- Small form factor facilitates sleek integration into your Digital Signage design
- Multiple sensors can be installed side-by-side with only 15cm interspacing to create a high-resolution detection grid for detecting where a person is standing
- Auto-calibration and auto-start for highly reliable applications (24/7)
- Status LED indicating trigger detection
PACKAGE CONTENTS: XY-231
Features
- Time-of-Flight presence sensor with distance measurement
- Adjustable 27° Field-of-View
- Up to 170cm detection distance
- Dedicated Airbutton zone for touchless user input
Specifications
Mounting specifications
- Mount in such a way that the sensor has a clear view (see panel cut out section for more info)
- Position the sensor in such a way that it is not directed perpendicular towards a window.
Field-of-View
- Range: 0-170cm
- Angle: 15-27°
Thermal specifications
- Operating temperature: +10´C...+40´C/ +50´F...+104´F
- Storage temperature: -20´C...+50´C/ -4´F...+122´F
Electrical specifications
- Operating voltage: 5V DC (via X-talk interface)
- Power consumption: 50mA
- IR Emitter: 940nm invisible laser
- Laser classification: Class 1
