HW Group - Vibration detector SS14-v2 - 600758
Vibration sensor
Producentens varenummer:
600758
Vores artikelnummer:
930188
Har du spørgsmål? Vi vil med glæde rådgive dig! → Kontaktformular
Produktinformation "HW Group - Vibration detector SS14-v2 - 600758"
SS14-v2 is a detection device of shocks and vibrations.
Is used to protect fixtures, windows, box, or any passage where is needed detect break-in attempts by vibrations or strong shocks.
Applications and usage
Scope of delivery: HW Group Vibration detector SS14-v2
Is used to protect fixtures, windows, box, or any passage where is needed detect break-in attempts by vibrations or strong shocks.
Applications and usage
- Intrusion detection
- Vibration detection
Scope of delivery: HW Group Vibration detector SS14-v2
| Monitoring: | Security |
|---|
Features
- Alarm contact output: Max 100 mA - 30 Vcc (Connect to DI of HWg devices)
- External power: 9-15V DC (9 - 20 mA)
- Tamper output: mechanical contact Max 200 mA - 24 Vcc
- Dimensions: 77x36x20 mm (ABS housing)
- Temperature: -20°C to +50°C
- Alarm state: LED indicator
- RFI protection 30V/m (20 MHz - 2000 MHz)
Specifications
Measurement
Measure
Vibration
Outputs:
Open colectors
Power and dimensions
Type
Measure
Vibration
- Cable length: None
- Galvanic isolation: YES
- Units Converter: NO
- Calibrated Points: None
- Number of values provided: 1
Outputs:
Open colectors
- Output load voltage: 30V DC
- Output load current: 100mA
- Def. impulses out: NO
- Local condition output: NO
Power and dimensions
- Power supply: 12V
- Consumption: 20mA
- Operating environment: -20°C – 50°C / 0%RH – 95%RH
- Storage environment: -20°C – 50°C / 0%RH – 95%RH
- Dimensions: 37 x 78 x 21 (WxHxD)
- Warranty: 24 months
Type
- Environment: Industrial, SoHo
- Protection: IP30
- Connectors: Terminal Block
- Design: Mural
