Advantech - ICR-2412
Router for LPWA communication Cat-M/Cat-NB/GPRS/EDGE with 2× ETH, 1× RS232, 1× RS485, No ACC
Producentens varenummer:
ICR-2412
Har du spørgsmål? Vi vil med glæde rådgive dig! → Kontaktformular
-
Beskrivelse Industrial cellular router ICR-2412 is designed for wireless communication in the LPWA mobile networks LTE Cat-M/Cat-NB wit… Mere
-
Egenskaber Features LPWA communication Cat-M/Cat-NB/GPRS/EDGE 450 MHz support (B31 & B72) 2× SIM for redundancy 2× Ethernet 10/100 Mb… Mere
-
Tekniske detaljer Technical details Region EMEA: Yes Interface ETH Port(s): 2 RS232: 1 I/O: 1 x DI + 1 x DO Antenna Connectors Cellular Ant… Mere
-
Datablad
Produktinformation "Advantech - ICR-2412"
Industrial cellular router ICR-2412 is designed for wireless communication in the LPWA mobile networks LTE Cat-M/Cat-NB with fallback to the traditional 2G GPRS/EDGE network. GPRS/EDGE 2G standard allows deployment at places where LTE Cat-M/Cat-NB signal coverage is still under development.
ICR-2412 is the ideal gateway for global IoT applications because of the large number of cellular frequency bands supported. Among others, the router supports also the European LTE 450 MHz spectrum (bands B31 and B72) that is a key frequency for wireless communication in critical infrastructure e.g. in Energy distribution.
The router is equipped with two independently configurable Ethernet ports (LAN or WAN), 1× serial port RS232, 1× RS485, and with digital I/O connectivity (1× DI, 1× DO). The router supports VPN tunnel creation using various protocols to ensure safe communications. The router provides diagnostic functions which include automatic monitoring of the wireless and wired connections, automatic restart in case of connection losses, and a hardware watchdog that monitors the router status.
Router is based on ICR-OS operation system. Open Linux platform enable wide possibilities of programming customer SW applications in Python, C/C++. Router supports uploading of RouterApps (User modules) that would extend standard firmware functionalities. Existing app library ready for free download by customer contains already developed software apps to enhance specific router functionality including industrial protocol conversions, support of IoT platforms such as MS Azure, Cumulocity, ThingWorx and a lot more.
Scope of delivery: Advantech - ICR-2412
ICR-2412 is the ideal gateway for global IoT applications because of the large number of cellular frequency bands supported. Among others, the router supports also the European LTE 450 MHz spectrum (bands B31 and B72) that is a key frequency for wireless communication in critical infrastructure e.g. in Energy distribution.
The router is equipped with two independently configurable Ethernet ports (LAN or WAN), 1× serial port RS232, 1× RS485, and with digital I/O connectivity (1× DI, 1× DO). The router supports VPN tunnel creation using various protocols to ensure safe communications. The router provides diagnostic functions which include automatic monitoring of the wireless and wired connections, automatic restart in case of connection losses, and a hardware watchdog that monitors the router status.
Router is based on ICR-OS operation system. Open Linux platform enable wide possibilities of programming customer SW applications in Python, C/C++. Router supports uploading of RouterApps (User modules) that would extend standard firmware functionalities. Existing app library ready for free download by customer contains already developed software apps to enhance specific router functionality including industrial protocol conversions, support of IoT platforms such as MS Azure, Cumulocity, ThingWorx and a lot more.
Scope of delivery: Advantech - ICR-2412
Features
- LPWA communication Cat-M/Cat-NB/GPRS/EDGE
- 450 MHz support (B31 & B72)
- 2× SIM for redundancy
- 2× Ethernet 10/100 Mbps
- 1× RS232, 1× RS485
- 1× DI, 1× DO
- Wide operational temperature range
- Wall and DIN mount options
- Linux based OS & SW customization
Technical details
Region
EMEA: Yes
Interface
ETH Port(s): 2
RS232: 1
I/O: 1 x DI + 1 x DO
Antenna Connectors
Cellular Antennas: 1 x SMA
Power
Power Input (DC): 9 ~ 48 VDC
Environment
Temperature (Operating Range): -40 ~ 75°C (-40 ~ 167°F)
Humidity (Operating Range): 0~95%
Mechanism
Dimensions (W x H x D): 103 x 25 x 95 mm
Enclosure (Metal): Metal
Mounting (DIN-rail): Yes
Mounting (Wall): Yes
Software
Advances Software Tool: WA/DMP, WA/VPN
Region
EMEA: Yes
Interface
ETH Port(s): 2
RS232: 1
I/O: 1 x DI + 1 x DO
Antenna Connectors
Cellular Antennas: 1 x SMA
Power
Power Input (DC): 9 ~ 48 VDC
Environment
Temperature (Operating Range): -40 ~ 75°C (-40 ~ 167°F)
Humidity (Operating Range): 0~95%
Mechanism
Dimensions (W x H x D): 103 x 25 x 95 mm
Enclosure (Metal): Metal
Mounting (DIN-rail): Yes
Mounting (Wall): Yes
Software
Advances Software Tool: WA/DMP, WA/VPN
