ADDERView Matrix - Switch 30 Port
Matrix switches for the ADDERView Matrix C-Range
Producentens varenummer:
AVM-C30
Vores artikelnummer:
490580
Har du spørgsmål? Vi vil med glæde rådgive dig! → Kontaktformular
Product information "ADDERView Matrix - Switch 30 Port"
Adder offers NETGEAR M4250 switch models for the ADDERView Matrix solution. Ideal for streamlined KVM solutions, these switches are preconfigured to support IGMP v2, snooping and Jumbo frame rate up to 9216 bytes, out-of-the-box. Available with 12 or 30 ports and with a mixture of CATX and SFP ports. Other switches can be used but must adhere to minimum specification.
PACKAGE CONTENTS:
- 1× AVM-C12 Matrix switch (NETGEAR GSM4212P)
- Country specific IEC mains cab
- Rack-mounting standard brackets
- Longer brackets for recessed mounting
- Rubber footpads for tabletop installation
- Quick start guide
| Port Number: | 8+ Ports |
|---|
Specifications
Link Ports
- 8p8c (RJ45): 26x
- SFP: 4x
Network Support
- Bandwidth: 1GbE
- 10/100 Support: Yes
Power Source
- Input Power Supply: Internal Power Supply Unit
- Output Power Supply: PoE (802.3.AF)
- Power Additional Information: 24 ports support 802.3.AF Total PoE budget of 300W
Power Consumption
- Maximum Power (Watts): 401
- Typical Power (Watts): 36
Physical Design
- Construction Material: Robust metal construction
- U size: 1
- Width: 440mm / 17.3i
- Height: 43.2mm / 1.7in
- Depth: 257mm / 10.10in
- Weight: 4.3kg / 9.5lb
